PDV-6US
The PDV-6US is a vertical power distributor that can be used in a wide variety of Sound Rack and/or Projector Pedestal applications and areas.
This device offers a high level of protection & safety using class D circuit breakers. The PDV-6US offers a trip current of 10 to 20 times the rated current with an operating time of 0.04 to 3 Seconds. It is also used for very high inductive loads.
The PDV-6US is easy to connect and flexible in transformation.
Description PDV-6US
Additional information
| Functions | Power Supply Distributor |
|---|---|
| Power Input | NEMA 5-15R, 15A 125V |
| Input Сonnectors | DIN rail Terminal Block |
| Output Сonnectors | 6 х NEMA 5-15R Socket, E314072 |
| Protection Сircuit Breaker | 3 x D16A on 2 Sockets |
| IP Protection | IP44 |
| Rack Install 19” | 3U |
| Dimensions | 483 x 133 x 92 mm – 19,02” x 5,24” x 3,63” |
| Net weight | 4,9 kg 10,80 lbs |
| PACKAGE CONTENTS | 1. PDV-6US – 1 pcs |
| OPTIONAL ACCESSORIES | Projector Pedestals PAP-Series |
We design, engineer and manufacture custom and standard cinema-centered mounts. We provide fast delivery.
